Accessories for agriculture

Connecting chain links

High tensile and hardness connecting links.

Dimensions and mechanical properties
Link size	d1	t1	t2	b1	l	d	b2	s	Load limit max.	Breaking force min.
Link size	mm								kN

8 x 31	8 ± 0,3	31 - 0,4	39	28,5	39	3	5	4	18	71
9 x 31	9 ± 0,4	31 - 0,5	40	32	40	3	5	5	22,4	90
10 x 31	10 ± 0,4	31 - 0,5	41	35	41	4	5	5	28	112
11 x 31	11 ± 0,4	31 - 0,5	42	38	42	4	6	6	38	160
12 x36	12 ± 0,5	36 - 0,6	43	39	45	5	6	6	41	170
13 x36	13 ± 0,5	36 - 0,6	47	41	47	5	7	7	47,5	190

Shackle acc. to DIN 22253, PN-G-46696

Dimensions and mechanical properties
Shackle size	b	t	c	d	e	i	m	n	p	f	g	Breaking force min.	Weight
Shackle size	mm											kN	kg/pcs.

14 x 50	15	50	78	17	78	19	15	32	17	51	29	225	0,7

Mechanical properties of bolt and nut
Shackle size	Thread symbol	Mechanical property		Nut tightening torque [Nm]
Shackle size	Thread symbol	bolt acc. to PN-82/M-82054/03	bolt acc. to PN-82/M-82054/09	Nut tightening torque [Nm]

14 x 50	M16	8,8	8	180

Sprockets for selected manure spreaders

We offer a wide range of sprockets that are a component of conveyor belt in agricultural machines.
