Bucket links for conveyors acc. to DIN 745, DIN 5699

Bucket links used to connect chain segments with buckets.

Dimensions and mechanical properties
Bucket size	t	a	b	d1	d2	d3	h	l	Weight	RC4		RC5
	t	a	b	d1	d2	d3	h	l	Weight	Proof load	Breaking load min.	Proof load	Breaking load min.
	mm								kg/pcs.	kN

T45	45	20	73	11,5	14	M10	40	25	0,17	26	59	28	63
T56	56	25	92	15	18	M12	50	32	0,36	45	99	46	107
T63	63	30	105	18	21	M16	60	40	0,6	64	143	67	153
T70	70	34	116	20	23	M20	68	45	0,9	79	176	82	189
T80	80	37	132	23	26	M20	74	45	1,13	104	233	109	250
T91	91	43	149	26	29	M24	86	55	1,83	133	298	139	319
T105	105	50	173	30	34	M24	100	55	2,4	177	396	184	425
